Exploded View Generator

By bogdi · Credited author: Bogdan Bogdanovic · 2016-03-22

Version
2.0.0
Version requirement
3ds Max 2014+
Date updated
2016-03-22
Votes
2
Homepage
https://apps.autodesk.com/3DSMAX/en/Detail/Index?id=appstore.exchange.autodesk.com%3aexplodedviewgenerator_windows32and64%3aen
External download
External download

Tags: generator, exploded view, exploded view animation

Description

Overall functionality and advantages

  • This script creates Exploded View effect by scaling the generated Master Controller (Box Helper)
  • The script works on a selection of multiple objects
  • It is very easy to use
  • Exploded View can also be animated

Additional Info

General Usage Instructions

  1. Position the objects on the center (0,0,0).
  2. Select the objects. Don't group the objects.
  3. Run the script from Exchange Store Menu available in menu bar.
  4. Please refer screenshot Exchange Store Menu.
  5. Press the Generate! Button.
  6. Scale the Master Control helper to see the effect.
